ZyXEL Communications P-334W - Manual (Page 465)

Prestige 334W User’s Guide
Setting up Your Computer’s IP Address E-5
5. Click OK to close the Network window. Insert the Windows CD if prompted.
6. Turn on your Prestige and restart your computer when prompted.
Checking/Modifying Your Computer’s IP Address
1. Click Start and then Run.
2. In the Run window, type "winipcfg" and then click OK to open the IP Configuration window.
3. Select your network adapter. You should see
your computer's (static) IP address, subnet
mask and default gateway in this screen. Verify
that your computer’s static IP address is in the
correct subnet (192.168.1.2 to 192.168.1.254 if
using the default Prestige LAN IP address).
Alternatively, to have the Prestige assign your
computer a new IP address (from the IP pool),
make sure your Prestige is turned on and click
Renew in this screen.
Your computer can now communicate with the
Prestige using the LAN port.
