Prestige 334W User’s Guide
Menu 3 LAN Setup 23-7
Figure 23-6 Menu 3.5 Wireless LAN Setup
The following table describes the fields in this menu.
Table 23-4 Menu 3.5 Wireless LAN Setup
FIELD DESCRIPTION EXAMPLE
ESSID
The ESSID (Extended Service Set IDentity) identifies the AP to which the
wireless stations associate. Wireless stations associating to the AP must
have the same ESSID. Enter a descriptive name of up to 32 printable 7-bit
ASCII characters. Wireless
Hide ESSID
Press [SPACE BAR] and select Yes to hide the ESSID in the outgoing data
frame so an intruder cannot obtain the ESSID through passive scanning. No
Channel ID
Press [SPACE BAR] to select a channel. This allows you to set the
operating frequency/channel depending on your particular region. CH06
2437MHz
RTS
Threshold Setting this attribute to zero turns on the RTS/CTS handshake. Enter a value
between 0 and 2432. 2432
Fragment
Threshold This is the maximum data fragment size that can be sent. Enter a value
between 256 and 2432. 2432
WEP Select Disable to allow wireless stations to communicate with the access
points without any data encryption. Disable
Menu 3.5 - Wireless LAN Setup
ESSID= Wireless
Hide ESSID= No
Channel ID= CH06 2437MHz
RTS Threshold= 2432
Frag. Threshold= 2432
WEP Encryption= Disable
Default Key= N/A
Key1= N/A
Key2= N/A
Key3= N/A
Key4= N/A
Authen. Method= N/A
Edit MAC Address Filter= No
Edit Roaming Configuration= No
Preamble= Long
802.11 Mode= Mixed
Press ENTER to Confirm or ESC to Cancel:
