Prestige 334W User’s Guide
25-6 Remote Node Configuration
25.2.3 PPTP Encapsulation
If you change the Encapsulation to PPTP in menu 11.1, then you will see the next screen. Please see the
appendix for information on PPTP.
Figure 25-3 Menu 11.1 Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed.
Table 25-3 Menu 11.1 Remote Node Profile for PPTP Encapsulation
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must
also go to menu 11.3 to check the IP Address setting once you have
selected the encapsulation method. PPTP
My IP Addr Enter the IP address of the WAN Ethernet port. 10.0.0.140
My IP Mask Enter the subnet mask of the WAN Ethernet port. 255.255.255.0
Server IP Addr Enter the IP address of the ANT modem. 10.0.0.138
Connection
ID/Name
Enter the connection ID or connection name in the ANT. It must
follow the “c:id” and “n:name” format.
This field is optional and depends on the requirements of your DSL
modem.
N:My ISP
Menu 11.1 - Remote Node Profile
Rem Node Name= MyISP Route= IP
Active= Yes
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name= N/A Allocated Budget(min)= 0
Outgoing: Period(hr)= 0
My Login= Schedules=
My Password= ******** Nailed-Up Connection= No
Retype to Confirm= ********
Authen= CHAP/PAP
PPTP: Session Options:
My IP Addr= Edit Filter Sets= No
My IP Mask= Idle Timeout(sec)= 100
Server IP Addr=
Connection ID/Name= Edit Traffic Redirect= No
Press ENTER to Confirm or ESC to Cancel:
