Prestige 334W User’s Guide
38-2 VPN/IPSec Setup
Figure 38-2 Menu 27 VPN/IPSec Setup
38.2 IPSec Summary Screen
Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 IPSec Summary. This is a summary
read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by selecting an index number and
then configuring the associated submenus.
Figure 38-3 Menu 27.1 IPSec Summary
Table 38-1 Menu 27.1 IPSec Summary
FIELD DESCRIPTION EXAMPLE
# This is the VPN policy index number. 1
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
Enter Menu Selection Number:
Menu 27.1 – IPSec Summary
# Name A Local Addr Start - Local Addr End Encap IPSec Algorithm
Key Mgt Remote Addr Start - Remote Addr End Secure GW Addr
- --------- - ------------------ -------------------- ------ ------------------
001 Taiwan Y 192.168.1.35 192.168.1.38 Tunnel ESP DES MD5
IKE 172.16.2.40 172.16.2.46 193.81.13.2
002 zw50 N 1.1.1.1 1.1.1.1 Tunnel AH SHA1
IKE 4.4.4.4 255.255.0.0 zw50test.zyxel.
003 China N 192.168.1.40 192.168.1.42 Tunnel ESP DES MD5
IKE N/A N/A 0.0.0.0
Select Command= None Select Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
