Prestige 334W User’s Guide
33-2 System Information and Diagnosis
Figure 33-2 Menu 24.1 System Maintenance : Status
The following table describes the fields present in Menu 24.1 — System Maintenance — Status. These
fields are READ-ONLY and meant for diagnostic purposes. The upper right corner of the screen shows the
time and date according to the format you set in menu 24.10.
Table 33-1 System Maintenance: Status Menu Fields
FIELD DESCRIPTION
Port Identifies a port (WAN, LAN or WLAN) on the Prestige.
Status Shows the port speed and duplex setting if you’re using Ethernet Encapsulation
and Down (line is down), idle (line (ppp) idle), dial (starting to trigger a call) and
drop (dropping a call) if you’re using PPPoE Encapsulation.
TxPkts The number of transmitted packets on this port.
RxPkts The number of received packets on this port.
Cols The number of collisions on this port.
Tx B/s Shows the transmission speed in Bytes per second on this port.
Rx B/s Shows the reception speed in Bytes per second on this port.
Up Time Total amount of time the line has been up.
Ethernet Address The Ethernet address of the port listed on the left.
IP Address The IP address of the port listed on the left.
Menu 24.1 - System Maintenance - Status 07:33:32
Wed. Dec. 24, 2003
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN 100M/Full 15982 938667 0 78 2520 2:07:57
LAN 100M/Full 22381 21235 0 2399 128 6:55:05
WLAN 54M 261 0 0 0 0 6:55:05
Port Ethernet Address IP Address IP Mask DHCP
WAN 00:A0:C5:01:23:46 172.1.2.3 255.255.0.0 Client
LAN 00:A0:C5:01:23:45 192.168.1.1 255.255.255.0 Server
System up Time: 6:55:10
Name:
Routing: IP
ZyNOS F/W Version: V3.60(JK.0)b1 | 01/28/2004
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
