Prestige 334W User’s Guide
NAT 28-5
Figure 28-5 Menu 15.1.255 SUA Address Mapping Rules
The following table explains the fields in this menu.
Menu 15.1.255 is read-only.
Table 28-2 SUA Address Mapping Rules
FIELD DESCRIPTION EXAMPLE
Set Name This is the name of the set you selected in menu 15.1 or enter
the name of a new set you want to create. SUA
Idx This is the index or rule number. 1
Local Start IP Local Start IP is the starting local IP address (ILA). 0.0.0.0
Local End IP Local End IP is the ending local IP address (ILA). If the rule is
for all local IPs, then the Start IP is 0.0.0.0 and the End IP is
255.255.255.255. 255.255.255.255
Global Start IP This is the starting global IP address (IGA). If you have a
dynamic IP, enter 0.0.0.0 as the Global Start IP. 0.0.0.0
Global End IP This is the ending global IP address (IGA).
Type These are the mapping types. Server allows us to specify
multiple servers of different types behind NAT to this machine.
See later for some examples. Server
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
