Chapter 5 Application Configuration Procedures IPmux-1/1E Installation and Operation Manual
5-16 Configuring the Management Option
MANAGER LIST
1. Manager IP Address 192.114.35.1
2. Status Change Trap On
3. Alarm Trap On
3. System Trap Off
ESC. Exit S. Save N. Next
Select item from the menu.
Figure 5-9. Manager List Menu
If you set Alarm Trap to Off no Alarm Trap will be sent, regardless of the mask
defined in the Alarm Trap Mask screen. For further details refer to Manager List in
the IPmux-4 or IPmux-1 manual.
Alarms Trap Mask
➤ To configure the Alarms Trap Mask:
1. From the Management Configuration menu, press 3 Alarms Trap Mask (see
Figure 5-10).
2. Select Trap Status and choose a value according to your application
requirements (for details refer to Alarms Trap Mask in the IPmux-4 manual.
ALARMS TRAP MASK
1. Alarm ID 1
2. Trap Status Active
ESC. Exit S. Save
ACTIVE ALARM TRAPS:
Figure 5-10. Alarms Trap Mask Menu
Default Gateway
If the Manager is not on the same subnet as IPmux-4, configure the Default
Gateway.
➤ To configure the Default Gateway:
1. From the General Configuration menu, press 2 Default Gateway (see
Figure 5-11).
2. Enter the Gateway IP Address.
Note
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
3. Management
Configuration
↓
3. Alarms Trap
Mask
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓↓↓↓
2. Default
Gateway
