IPmux-1/1E Installation and Operation Manual

Chapter 2 Installation

Installation and Setup

2-7

Table 2-1. E1/T1 Port Connectors Pinout

Pin Designation Direction

Function

1

RD (R)

Input

Receive data (ring)

2

RD (T)

Input

Receive data (tip)

3,6 –

–

FGND

4

TD (R)

Output

Transmit data (ring)

5

TD (T)

Output

Transmit data (tip)

7,8 –

N/A

Not

connected

Table 2-2. Ethernet Port Pinout

Pin

Pinout

1 Tx+

2 Tx–

3 Rx+

4 –

5 –

6 Rx–

7 –

8 –

Table 2-3. Control Port Pinout

Pin

Pinout

1 –

2 Rx

3 Tx

4 –

5 GND

6 –

7 –

8 –

9 –
