IPmux-1/1E Installation and Operation Manual Appendix E Parameters and Screens
IPmux-1E ISDN Configuration E-21
Table E-13. ISDN Configuration
Parameter Possible Values Remarks
Interfaces Mode Terminal
Network ISDN S ports are in TE mode
ISDN S ports are in NT mode
Transmit Clock Source ???? Adaptive
Loopback
Internal
Adaptive clock regeneration
Only when IPmux-1E BRI ports are
configured as TE mode – clock is taken
from the opposite NT device connected
to Channel 1
Local clock source is used
Channel Configuration Next screen
ISDN Channel Configuration
ISDN CHANNEL CONFIGURATION
1. Channel Number 1
2. Channel Status Enable
3. Loopback Status Disable
4. Phantom Feeding Disable
ESC. Exit
Select item from the menu.
Figure E-22. ISDN Channel Configuration Menu
Table E-14. ISDN Channel Parameters
Parameter Possible Values Remarks
Channel Number 1, 2, 3, 4 Select chanel to be configured
Channel Status Enable
Disable Channel is enabled
Channel is disabled
Loopback State Disable
Internal
External No loopback; regular operation
An internal loop on IPmux-1E tests the ISDN S line
An external loop on IPmux-1E tests the ISDN S line
Phantom Feeding Enable, Disable Read-only according to jumper setting on the board
Main Menu
↓
2. Configuration
↓
2. ISDN
Configuration
↓
3. ISDN
Channel
Configuration
