Appendix E Parameters and Screens IPmux-1/1E Installation and Operation Manual
E-24 Analog Configuration
Signaling Profile Configuration
SIGNALING PROFILE CONFIGURATION
1. Rx A A
2. Rx B N/C
3. Rx C N/C
4. Rx D N/C
5. Tx A A
6. Tx A 1
7. Tx A 0
8. Tx A 1
ESC. Exit
+------------------------+
| Rx: From Network |
| Tx: To Network |
+------------------------+
Select item from the menu.
Figure E-25. Signaling Profile Configuration Parameters
Table E-17. Signaling Profile Configuration
Parameter Possible Values Remarks
Rx A A, A Inverse, N/C Specifies which ABCD Signaling Bit (only one), and its polarity,
carries the on hook/off hook information from the far-end device
Rx B B, B Inverse, N/C Specifies which ABCD Signaling Bit (only one), and its polarity,
carries the on hook/off hook information from the far-end device
Rx C C, C Inverse, N/C Specifies which ABCD Signaling Bit (only one), and its polarity,
carries the on hook/off hook information from the far-end device
Rx D D, D Inverse, N/C Specifies which ABCD Signaling Bit (only one), and its polarity,
carries the on hook/off hook information from the far-end device
Tx A A, A Inverse, 0, 1 Specifies which ABCD Signaling Bit carries the on hook/off hook
information to the far-end device. One or more can be configured to
carry the off-hook/on-hook information (or inverse information),
while the other bits should be set to ‘1’ or ‘0’.
Main Menu
↓
2. Configuration
↓
2. Analog
Configuration
↓
4. Signaling
Profile
Configuration
