Chapter 1 Introduction IPmux-1/1E Installation and Operation Manual
1-8 Overview
Table 1-1. Fiber Options
Interface Type Wavelength
(nm)
Optical Power
(dBm)
Min Max
Receive
Sensitivity
(dBm)
Optical
Budget
(dB)*
Loss
(dB/km)
Min Max
SC Multimode 1300 –20 –14 –31 8* 1 4
SC Single mode 1300 –20 –14 –31 8* 0.5 0.8
LC Multimode 1300 –19 –14 –32 10* 1 4
LC Single mode 1300 –15 –8 –32 14* 0.5 0.8
• Permitted fiber optic cable length differs according to fiber characteristics,
splices, and connectors.
When a user port option (only UTP) is chosen, the network fiber option is LC. If
there is no user port, the network fiber option is SC.
➤
To calculate Optical Budget:
Optical Budget [dB] =
Receive Sensitivity–Optical Power–3 (Aging) – Connectors/Patch Panels Loss
➤
To calculate Distance:
Distance = Optical Budget/Maximum Loss
Mode of Operation
IPmux-1 can operate in three different modes:
• Unframed E1/T1 over UDP over IP over Ethernet
• Fractional E1/T1 over UDP over IP over Ethernet
• Fractional E1/T1 with CAS over UDP over IP over Ethernet.
IPmux-1E with BRI can operate in two modes:
• NT mode
• TE mode.
IPmux-1E with FXS can operate in three modes:
• E1 mode
• T1 mode D4 mode
• T1 ESF mode.
