Chapter 3 Operation

IPmux-1/1E Installation and Operation Manual

3-12 Overview of Menu Operations

CONFIGURATION

1. General Configuration

2. Analog Configuration

3. Bundle Connection Configuration

4. LAN Configuration

ESC. Exit

Select item from the menu:

Figure 3-12. IPmux-1E FXS Configuration Menu

From the Configuration menu you can view and configure the following options:
1. General Configuration

Configure Host IP, Default Gateway,

ASCII Terminal Configuration, Time/Date
update, and Default parameters, and

download software updates.

2. E1/T1/ISDN/FXS Configuration

E1/T1, ISDN, or FXS physical layer

configuration.

3. Bundle Connection Configuration

Configure Connection parameters:

Configure IP ToS, TDM bytes/frame and

VLAN tagging.

4. LAN Configuration

Ethernet physical layer configuration.

5. DS0 Bundle Configuration

Configure TS assignment to the bundle
(only for IPmux-1).

Specific parameters are explained in Appendix E.

DS0 Bundle Configuration is only available in IPmux-1.

Note
