IPmux-1/1E Installation and Operation Manual
Appendix E Parameters and Screens
Performance Monitoring
E-35
Bundle Connection Statistics
BUNDLE CONNECTION STATUS
Destination IP Address:
192.192.192.1
Next Hop MAC Address:
00-00-00-00-00-00
Connectivity Status:
LOCAL FAIL
Sequence Errors:
0
Jitter Buffer Underflows:
1
Jitter Buffer Overflows:
0
Esc. Exit
R. Reset Counters
Figure E-33. Bundle Connection Status Menu
➤
To reset counters:
• Type R.
Table E-24. Bundle Connection Status Parameters
Parameter Possible
Values
Remarks
Destination IP Address
Destination IP address of the bundle configured
under Bundle Connection Configuration
Destination Mac Address
In this screen Destination Mac Address displayed is
in fact the resulting Mac Address of the ARP
process for the destination IP address.
Connectivity Status
Disabled
OK
Local Failure
Remote Failure
Channel is disabled
Connection is Ok. Frames are received by the
remote and the local IPmux
Frames are not received by the local IPmux
Frames are not received by the remote IPmux
Sequence Errors
The number of times a frame was dropped
because frames were received from the network
with SN fields not equal to the last SN+1 (or 2)
Main Menu
↓
3. Performance
Monitoring
↓
3. Bundle
Connection
Statistics
