Appendix E Parameters and Screens IPmux-1/1E Installation and Operation Manual
E-22 Analog Configuration
E.6 Analog Configuration
ANALOG CONFIGURATION
1. Clock Source Adaptive
2. Far End Type E1
3. Channel Configuration >
4. Signaling Profile Configuration >
ESC. Exit
+----------------------------------------+
|NOTICE: The connection must be disabled |
| before any changes! |
+----------------------------------------+
Select item from the menu.
Figure E-23. Analog Configuration Menu
Table E-15. Analog Configuration
Parameter Possible Values Remarks
Clock Source Internal
Adaptive Local clock source is used
Adaptive clock regeneration
Far End Type E1
T1-ESF, T1-D4 Sets A-Law/µ-Law and TDMoIP
encapsulation mode
Channel Configuration Next screen
Signaling Profile Configuration Next screen
Main Menu
↓
2. Configuration
↓
2. FXS
Configuration
