IPmux-1/1E Installation and Operation Manual

Chapter 5 Application Configuration Procedures

IPmux-1 5-7

Remember to press <Enter> after modifying each parameter. Press <S> to save

all changes on the menu.

DS0 BUNDLE CONFIGURATION

1. Bundle ID

2. Time Slot Number

1–10

3. Time Slot Current Status

Set

ESC. Exit

ACTIVE TIME SLOTS IN THIS BUNDLE:

1–10

FREE TIME SLOTS:

11,12,13,14,15,
16,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31

Select item from the menu.

Figure 5-4. DS0 Bundle Configuration Menu

Bundle Connection Configuration

➤

To link the bundles to IPmux-4:
1. From the Configuration menu select 3 Bundle Connection Configuration

(see Figure 5-5).

2. Select Connection Status and choose Enable.
3. Select Destination IP Address and enter the IP Address of IPmux-4.
4. Select Next Hop and enter the next hop router IP address (this parameter is

only necessary if the Destination IP Address is not in the same subnet as this
IPmux. In such cases the Ethernet frame will be sent to the next hop IP

address).

5. Select Destination Bundle and enter 32 (which is the destination bundle on

IPmux-4).

6. Press <Esc> a few times to return to the Main menu.

Remember to press <Enter> after modifying each parameter. Press <S> to save

all changes on the menu.

Main Menu

↓

2. Configuration

↓↓↓↓

3. Bundle
Connection

Configuration

Note
