Figure 1-4. u interface concentration, Figure 1-5. extending bri ports of a small office – RAD Data comm IPmux-1 User Manual
Page 13
IPmux-1/1E Installation and Operation Manual
Chapter 1 Introduction
Overview
1-5
Fast Ethernet
Switch
Computer
Workstation
Computer
Workstation
ISDN Telephone
ISDN Telephone
IPmux-1
Telephone
Switch
TE U Ports
E1 CAS
For BRI
Grooming
For FXS
Grooming
E1 Link
Megaplex
IPmux-1
Fast Ethernet
Switch
ISDN Telephone
ISDN Telephone
ISDN Telephone
ISDN Telephone
IPmux-1
Fast Ethernet
Switch
POTS
Network
Figure 1-4. U Interface Concentration
Network
IPmux-1E
S
PBX
ISDN Telephone
ISDN Telephone
Computer
Workstation
Computer
Workstation
NT
IPmux-1E
TE
Figure 1-5. Extending BRI Ports of a Small Office
