Chapter 5 Application Configuration Procedures IPmux-1/1E Installation and Operation Manual
5-8 IPmux-1
BUNDLE CONNECTION CONFIGURATION
1. Bundle ID 1
2. IP TOS Empty!
3. TDM Bytes in Frame 48
4. Connection Status Empty!
5. Destination IP Address 192.168.200.10
6. Next Hop Empty!
7. Destination Bundle Empty!
8. Jitter Buffer
µµµµsec> rounded up 1000 µµµµsec steps! 3 ms
9. VLAN Tagging Empty!
10. VLAN ID Empty!
11. VLAN Priority Empty!
ESC. Exit
Select item from the menu.
Figure 5-5. Bundle Connection Configuration
TDM Bytes in Frame and Jitter Buffer are automatically set to default values: 48
for TDM Bytes, 3 ms for Jitter Buffer.
Configuring IPmux-1 – Station B
Power-up in the same manner as for IPmux-1 Station A.
Host IP Address
Frames will not leave the device until IP and Mask addresses are defined.
➤ To configure the Host IP Address:
1. From the Main menu, select 2 Configuration.
2. From the Configuration menu select 1 General Configuration.
3. From the General Configuration menu, press 1 Host IP (refer to Figure 5-2).
4. Enter the Host IP Address and Mask.
5. Press <Esc> a few times back to the General Configuration menu.
Note
Note
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓↓↓↓
1. Host IP
