IPmux-1/1E Installation and Operation Manual

Appendix E Parameters and Screens

Bundle

Connection

Configuration

E-25

Table E-17. Signaling Profile Configuration (Cont.)

Parameter Possible

Values

Remarks

Tx B

B, B Inverse, 0, 1

Specifies which ABCD Signaling Bit carries the on hook/off hook
information to the far-end device. One or more can be configured to
carry the off-hook/on-hook information, while the other bits should
be set to ‘1’ or ‘0’.

Tx C

C, C Inverse, 0, 1

Tx D

D, D Inverse, 0, 1

For example, if Rx = A, then all other Rx must be NC. If Rx = A Inverse, then all

other Rx must be NC. Tx can be A, B , 0, 1.

E.7 Bundle Connection Configuration

BUNDLE CONNECTION CONFIGURATION

1. Bundle ID

2. IP TOS

3. TDM Bytes in Frame

4. Connection Status

Disable

5. Destination IP Address

0.0.0.0

6. Next Hop

0.0.0.0

7. Destination Bundle

8. Jitter Buffer (x10

µµµµsec) rounded up 1000 µµµµsec steps! 300

9. VLAN Tagging

YES

A. VLAN Id

B. VLAN Priority

ESC. Exit

Select item from the menu.

Figure E-26. Bundle Connection Configuration

Parameters must be configured for each connection. To configure all parameters,

first select the bundle ID and then proceed with the parameter configuration.

VLAN ID and

VLAN Priority are
configurable only if
VLAN Tagging is
set to Yes.

Main Menu
↓

2. Configuration
↓

3. Bundle
Connection

Configuration

Note
