IPmux-1/1E Installation and Operation Manual Chapter 1 Introduction
Overview 1-3
100 Mbps
Fiber
10/100 Mbps
IPmux-1
PBX
Fractional
E1/T1
Public Internet
Ethernet
Switch
Fractional
E1/T1
PBX IPmux-1
100 Mbps
IPmux-16
or
IPmux-4
n E1/T1 ×
Ethernet
Switch
PBX
PSTN
IP Network
Figure 1-2. E1/T1 Circuit Extension over an IP Based Network
