IPmux-1/1E Installation and Operation Manual
Appendix E Parameters and Screens
Ethernet Configuration/Statistics Menus
E-39
LAN statistics are not collected in intervals.
➤
To view statistics for next channel:
• Press N.
LAN STATISTICS
Mac Address
00-20-D2-16-3B-3D
Mode
Half
duplex
Rate(Mbps)
10
Status
Not
connected
Frames received
Total
Frames:
0
Total
Octets:
0
Frames transmitted
Correct
frames:
0
Correct
Octets:
0
Channel: Internal
Esc. Exit
R. Reset Counters
N. Next Channel
Figure E-38. LAN Statistics Menu – Two Ethernet Ports (Internal)
➤
To reset counters:
Type R.
