Appendix E Parameters and Screens IPmux-1/1E Installation and Operation Manual
E-12 General Configuration
Table E-8. Download/Upload Using X-Modem Parameters
Parameter Possible Values Remarks
File Application code,
Configuration code, Boot code
Download/Upload D
U Download a software or configuration file
Upload a configuration file
TFTP
DOWNLOAD/UPLOAD USING TFTP
1. File name
2. Command No Operation
3. Server IP 0.0.0.0
4. Retry timeout 15
5. Total timeout 60
6. View transfer status
ESC. Exit
Select item from the menu.
Use key or keys <1> to <6>.
Figure E-16. Download/Upload Using TFTP Window
Table E-9. Download/Upload Using TFTP Parameters
Parameter Possible Values Remarks
File name
Command No Operation,
Software Download,
Configuration Download,
Configuration Upload
Server IP IP address of the server from which the file is
loaded
Retry Timeout Selected retry timeout period (in seconds)
Total Timeout Selected total timeout period (in seconds), which
is the maximum time allowed for attempted
transmission
View Transfer Status View the transfer status in real-time. It is updated
every second. The screen is read-only.
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
6. Software
Download
↓
2. Download/
Upload by
TFTP
