IPmux-1/1E Installation and Operation Manual Appendix E Parameters and Screens
Ethernet Configuration/Statistics Menus E-37
Aging Time
SWITCH CONFIGURATION
1. LAN Configuration >
2. Aging Time 120
ESC. Exit
Select item from the menu.
Figure E-35. Switch Configuration – Two Ethernet Ports
Select Aging Time from 10 to 450 seconds.
LAN Configuration
LAN CONFIGURATION
1. Channel Network
2. Channel Status Enable
3. Auto Negotiation Enable
4. Max Capability advertised 100BaseT Full Duplex
5. Default type 100BaseT Full Duplex
6. Rate limit <0-Disable> 0
ESC. Exit N. Next
Select item from the menu.
Figure E-36. LAN Configuration – Two Ethernet Ports
Table E-25. LAN Configuration – Two Ethernet Ports
Parameter Values Remarks
Channel Network, User Selects port to be configured
Channel Status Enable, Disable When disabled, Ethernet LOS
Events will not be sent to the
Logfile
Auto Negotiation Enable, Disable
Max Capability
advertised 10BaseT Full Duplex,
10BaseT Half Duplex,
100BaseT Full Duplex,
100BaseT Half Duplex Default: 100baseT Full Duplex
Note: This parameter is valid only
when the Auto Negotiation mode is
enabled (RFC 2239).
Default type 10BaseT Full Duplex,
10BaseT Half Duplex,
100BaseT Full Duplex,
100BaseT Half Duplex
Default: 100baseT Full Duplex
Note: This parameter is valid only
when the Auto Negotiation mode is
enabled (RFC 2239).
Main Menu
↓
2. Configuration
↓
4. Switch
Configuration
↓
1. LAN
Configuration
Main Menu
↓
2. Configuration
↓
4. Switch
Configuration
↓
2. Aging Time
