Appendix E Parameters and Screens IPmux-1/1E Installation and Operation Manual
E-8 General Configuration
Manager List
The Manager List window parameters are used when IPmux-1 inband
management capability is used. The parameters define the parameters for up to
eight managers. These parameters are:
• Manager IP address
• Host index
In addition, the Manager List window parameters configure the traps to be
received by a manager. The default value for all traps is Off.
➤ To access additional manager-list parameters:
• Press to go to the next Manager List window.
MANAGER LIST
1. Manager IP Address 192.333.234.172
2. Alarm Trap On
3. Status Change Trap On
ESC. Exit S. Save N. Next
Select item from the menu.
Use key or keys <1> to <3>
Figure E-11. Manager List Menu
Table E-3. Manager List Parameters
Parameter Possible Values Function
Manage IP Address 0.0.0.0. to
255.255.255.255
Set the manager IP address
Alarm Trap On
Off The alarm trap informs the manager of the
occurrence of any alarm enabled in the Alarms
Trap Mask screen. It informs the manager of both
entry and exit from an alarm state.
No Alarm Trap will be sent regardless of the Mask
defined in the Alarm Trap Mask screen
Status Change Trap On
Off The status-change trap informs the manager that a
LED indicator on the front panel has changed its
indication.
No Status Change Trap will be sent
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
3. Management
Configuration
↓
2. Manager
List
