IPmux-1/1E Installation and Operation Manual Chapter 5 Application Configuration Procedures
IPmux-4 5-13
Remember to press <Enter> after modifying each parameter. Press <S> to save
all changes on the menu.
Bundle Connection Configuration
➤ To link the bundles to IPmux-1 Station A:
1. From the Configuration menu select 5 Bundle Connection Configuration
(see Figure 5-7).
2. Select Bundle ID and enter 32.
3. Select Connection Status and choose Enable.
4. Select Destination IP Address and enter the IP Address of IPmux-1 Station A.
5. Select Next Hop and enter the next hop router IP address (this parameter is
only necessary if the Destination IP Address is not in the same subnet as this
IPmux. In such cases the Ethernet frame will be sent to the next hop IP
address).
6. Select Destination Bundle and enter 1 (which is the destination bundle on
IPmux-1 Station A).
7. Press to save the configuration.
8. Press <Esc> to return to the Bundle Connection Configuration screen.
1. Remember to press <Enter> after modifying each parameter. Press <S> to
save all changes on the menu.
2. TDM Bytes in Frame and Jitter Buffer are automatically set to default values:
48 for TDM Bytes, 3 ms for Jitter Buffer.
➤ To link the bundles to IPmux-1 Station B:
1. From the Configuration menu select 5 Bundle Connection Configuration
(see Figure 5-7).
2. Select Bundle ID and enter 33.
3. Select Connection Status and choose Enable.
4. Select Destination IP Address and enter the IP Address of IPmux-1 Station B.
5. Select Next Hop and enter the next hop router IP address (this parameter is
only necessary if the Destination IP Address is not in the same subnet as this
IPmux. In such cases the Ethernet frame will be sent to the next hop IP
address).
6. Select Destination Bundle and enter 1 (which is the destination bundle on
IPmux-1 Station B).
7. Press to save the configuration.
Main Menu
↓
2. Configuration
↓↓↓↓
5. Bundle
Connection
Configuration
Note
Note
Main Menu
↓
2. Configuration
↓↓↓↓
5. Bundle
Connection
Configuration
