Appendix E Parameters and Screens IPmux-1/1E Installation and Operation Manual
E-40 Ethernet Configuration/Statistics Menus
Table E-26. LAN Statistics – Two Ethernet Ports
Statistics Values Description
MAC Address Hard Coded Port local MAC address
Mode Half duplex, Full duplex Port mode is set by either the default mode or via auto
negotiation results
Rate 10Mbps, 100Mbps Port rate is set by either the default mode or via auto
negotiation results
Status Not connected, Connected Not connected: Link loss
Connected: Normal operation
Frames received
Total Frames Total number of correct frames received
Total Octets Total number of correct octets received
Oversize Frames Number of frames that are too long, and CRC is valid
Fragments Number of frames that are shorter than 64 bytes and
have an invalid CRC
Jabber Number of frames that are too long and have an
invalid CRC
Dropped Frames Number of dropped frames due to delivery problems
CRC Errors The number of good frames with invalid CRC
Frames transmitted
Correct Frames Total number of frames successfully transmitted
Correct Octets Total number of octets successfully transmitted
Collision A counter of successfully transmitted frames for which
transmission is inhibited by collision event, valid only
in half duplex mode.
Channel1 Network, User, Internal
