IPmux-1/1E Installation and Operation Manual Appendix E Parameters and Screens
Analog Configuration E-23
Channel Configuration
CHANNEL CONFIGURATION
1. Channel Number 1
2. Channel Status Enable
3. Rx Gain –4dBm
4. Tx Gain 0dBm
5. Testing Disable
ESC. Exit
Select item from the menu.
Figure E-24. Channel Configuration Menu
Table E-16. Analog Configuration
Parameter Possible Values Remarks
Channel Number 1,2,3,4 Selects channel to be configured
Channel Status Enable
Disable Channel is enabled
Channel is disabled
Rx Gain –10, –8, –6, –4, –2, 0, 1, 2, 3, 4, 5 (dBm) Sets the gain towards the phone
Tx Gain –10, –8, –6, –4, –2, 0, 1, 2, 3, 4, 5 (dBm) Sets the analog gain as transmitted
from the phone to configure the
analog receiver dynamic range
Testing Tone Injection
Remote Loopback
Disable
1 kHz tone is injected towards the
local phone
A remote loopback analog signal is
set for IPmux-1E FXS
Main Menu
↓
2. Configuration
↓
2. FXS
Configuration
↓
3. Channel
Configuration
