IPmux-1/1E Installation and Operation Manual Appendix E Parameters and Screens
General Configuration E-11
Time/Date Update
TIME/DATE UPDATE
1. Set Time (hh:mm:ss) 16:09:12
2. Set Date (yyyy-mm-dd) 2001-04-17
ESC. Exit
Select item from the menu:_
Use key or keys <1> to <2>
Figure E-14. Time/Date Update Menu
Table E-7. Time/Date Update Parameters
Parameter Possible Values Remarks
Set Time 00:00:00 – 23:59:59 Time setting in the device
Set Date 1970/01/01 – 2099/01/01 Date setting in the device
Download/Upload Using Xmodem
Only configuration files can be uploaded. If you enter a software file, the
U. Upload
option is not displayed.
➤ To Download/Upload using Xmodem:
1. On the Software Download menu, select 1 (Download/Upload Using
Xmodem).
A confirmation message appears.
2. Select Y.
Upon confirmation, the download or upload procedure begins.
DOWNLOAD/UPLOAD USING XMODEM
1. File Application code
ESC. Exit D. Download
Select item from the menu.
Use key or keys <1> to <1>
Figure E-15. Download/Upload Using X-Modem Window
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
5. Time/Date
Main Menu
↓
2. Configuration
↓
1. General
Configuration
↓
6. Software
Download
↓
1. Download/
Upload by
X-Modem
