IPmux-1 E1/T1 Configuration

E-17

T1 Configuration

T1 CONFIGURATION

1. Channel Status

Enable

2. Transmit Clock Source

Adaptive

3. Loopback State

Disable

4. Line Type

T1-ESF

5. Line Code

B8ZS

6. Line Mode

DSU

7. Line Length/Tx Gain

0-133

8. Restore Time

1 second

9. Idle Code

A. Signaling Mode

CAS enable

B. Cond. Data pattern

C. Cond. CAS (AB/ABCD) pattern

D. Cond. CAS first 2.5 sec pattern(FF=NULL) FF

ESC. Exit

Select item from the menu.

Figure E-20. T1 Physical Layer Configuration Menu

When “unframed” mode is selected, the Restore Time, Idle Code, Signaling Mode,

Cond Data Pattern, Cond CAS (AB/ABCD) Pattern and Cond. CAS first 2.5 sec

pattern (FF=NULL) fields are not present.

When CAS Disabled is selected, the Cond CAS Pattern and Cond. CAS first 2.5 sec

pattern (FF=NULL) fields are not present.

Note

Main Menu
↓

2. Configuration
↓

2. E1/T1
Configuration
