Appendix
228
r
G-70 Music Workstation
(5) Use the screws that you removed in step 2 to fas-
ten the cover back in place.
■Checking whether the board is recognized
After installing the wave expansion, check to confirm
that the installed board is recognized correctly.
(1) Turn on the power, as described in “Switching the
(2) Press the [MENU] button and the [UTILITY] field.
(3) Press the [INFO] field to select the following page:
Check whether the name of the installed Wave
Expansion Board is displayed.
If “No SRX Card” is displayed next to “SRX Expansion
Board”, the wave expansion board is not recognized.
Re-install the wave expansion board correctly.
(4) Press [EXIT] to return to the main page.
Accessing the ‘Patches’ of SRX-
series expansion boards via MIDI
As you will notice, the CC00 number is always “93”. The
CC32 value, on the other hand, depends on (i) the board
you installed and (ii) the sound you need.
The MIDI standard can only handle 128 program
change numbers, which is why boards with more than
128 Patches use several consecutive CC32 values.
Patches
CC00
CC32
SRX-1
1~41
93
00
SRX-2
1~50
93
01
SRX-3
1~128
93
02
SRX-4
1~128
93
03
SRX-5
1~128
93
04
SRX-5
129~256
93
05
SRX-5
257~312
93
06
SRX-6
1~128
93
07
SRX-6
129~256
93
08
SRX-6
257~384
93
09
SRX-6
384~448
93
10
SRX-7
1~128
93
11
SRX-7
129~256
93
12
SRX-7
257~384
93
13
SRX-7
385~475
93
14
SRX-8
1~128
93
15
SRX-8
129~256
93
16
SRX-8
257~384
93
17
SRX-8
385~448
93
18
SRX-9
1~128
93
19
SRX-9
129~256
93
20
SRX-9
257~384
93
21
SRX-9
385~414
93
22
SRX-10
1~100
93
23
