Chapter 4

Human Machine Interface

BridgeVIEW User Manual

4-2

© National Instruments Corporation

There are several general G programming principles with which you should
be familiar before you build an HMI. These principles are listed below:

Building basic G front panels and diagrams

Using controls and indicators

Using the tag data type

Using the basic principles of dataflow programming

Using basic programming constructs such as the Sequence structure
and While Loop

Using the Time and Dialog VI library

To learn about any of the topics above, see the

G Tutorial

section of this

manual and complete the activities. For more detailed information, see the
G Programming Reference Manual.

For more advanced HMI programming, you also should know how to use
the G control and indicator attribute nodes and the VI Server functions.
For more information about this topic, see Chapter 13,

Front Panel Object

Attributes

, and Chapter 15,

Application Control

.

You might want to divide your HMI into several panels so the operator can
navigate through them using buttons on the screen. The Panel G Wizard
helps you generate the navigation system by automatically generating code
and attaching it to front panel buttons. For more information about the
Panel G Wizard, see Chapter 7,

Advanced Application Topics

.

How Do You Build an HMI?

To build an HMI, use the graphical controls and indicators to lay out the
user interface objects on the front panel, and a special set of VI libraries
on the block diagram to do the following:

Read and write tag values

View and acknowledge alarm states and events

Display historical and real-time data

Read tag configuration and security information

Control the BridgeVIEW system programmatically

Access and change tag attributes

Control output tags
