NEC Express5800/120Rh-2 N8100-1126F User Manual
Page 39
General Description 2-7
11 UID (Unit ID) switch
Press this switch to turn on/off the UID LEDs on the front and rear panels of the server.
Pressing the switch once turns on the LEDs. Pressing it again turns them off.
12 DUMP switch
Press this switch to dump memory.
13 Serial port A (COM A) connector
Connect device having a serial interface to this connector. Use COM B connector to
communicate with the remote console. A leased line cannot be connected directly to this
connector.
14 USB connectors
Connect device compliant with the USB interface to this connector.
15 VGA connector
Connect the display unit to this connector.
16 LINK/ACT LED (green)
This LED indicates the access status of the LAN.
17 LAN connectors
Connect network systems on the LAN to the connectors.
The number "1" following the bold-faced number indicates LAN port 1, and the number "2"
indicates LAN port 2.
18 Speed LED (amber)
This LED indicates the transmission speed of the LAN.
