4-6 Configuring Your Server
Primary IDE Master/Primary IDE Slave/Secondary IDE Master/Secondary IDE
Slave/Serial ATA Channel 0 Master/ Serial ATA Channel 1 Master
Correspondence between the menu items and devices:
„ Primary IDE Master: ATA hard disk drive 1 (option)
„
Primary IDE Slave: ATA hard disk drive 2 (option)
„ Secondary IDE Master: CD-ROM drive (standard)
„ Secondary IDE Slave: None
„
Serial ATA Channel 0 Master: Serial ATA hard disk drive 1 (option)
„ Serial ATA Channel 1 Master: Serial ATA hard disk drive 2 (option)
Option Parameter Description Your Setting
Type None
User
[Auto]
CD-ROM Selects the type of device attached to
the IDE or serial ATA channel. It is
strongly recommended to keep the
factory setting [Auto].
The following options do not appear when None or Auto are selected for Type.
Multi-Sector
Transfers
Disabled
2 Sectors
4 Sectors
8 Sectors
16 Sectors Specifies the number of sectors that
are transferred per block during
multiple sector transfers.
LBA Mode Control Enabled
Disabled Enable/disable LBA instead of
cylinder, head, sector, addressing.
Transfer Mode Standard
Fast PIO 1
Fast PIO 2
Fast PIO 3
Fast PIO 4
FPIO 3/DMA1
FPIO 4/DMA2 Select the method for moving data
to/from the drive.
Ultra DMA Disabled
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
Mode 5 Select the Ultra DMA mode used for
moving data to/from the drive.
[ ]: Factory-set
