9-10 Upgrading Your Server
Removal
Take the following steps to remove a hard disk drive:
NOTE: If removing a failing hard disk drive, confirm the slot in which
the DISK LED of the hard disk drive is amber before starting the
removal.
1. See the section "Preparing for Installation and Removal" described earlier to prepare.
2. Unlock the front bezel with the security key, and remove the front bezel.
3. Push the lever to unlock, and put the handle down.
4. Firmly hold the handle and hard disk drive, and pull out the hard disk drive.
5. If using the server with the hard disk drive removed, install the dummy block in the empty
slot.
1
2
6. Install the front bezel you removed in step 2.
DISK LEDs
