9-56 Upgrading Your Server
6. Change the jumper (J11) setting as shown in figure below.
J11
IMPORTANT: To avoid system malfunction, leave other jumpers at
its default position.
If the remote management card is installed in your server, follow these steps to configure
the firmware program.
7. Place the NEC EXPRESSBUILDER CD-ROM into the CD-ROM drive and reboot the
server.
8. Run "Initialize Remote Management Card".
Refer to Chapter 6 for details.
Standard Redundant
configuration
: Strap
FRONT REAR
Mother board
