Configuring Your Server 4-11
Peripheral Configuration
IMPORTANT: Note that the interrupt and/or base I/O address are not
overlapped with others. If the value set for the interrupt or base I/O
address is used in another resource, the yellow asterisk (*) appears.
Reset any item with the yellow asterisk properly.
Option Parameter Description Your Setting
Serial Port A Disabled
[Enabled]
Auto Selects whether serial port A is
enabled or disabled.
Base I/O address [3F8]
2F8
3E8
2E8 Selects the base I/O address for serial
port A.
Interrupt IRQ 3
[IRQ 4] Selects the interrupt for a serial port A.
Serial Port B Disabled
[Enabled]
Auto Selects whether serial port B is
enabled or disabled (display only).
Base I/O address 3F8
[2F8]
3E8
2E8 Selects the base I/O address for serial
port A.
Interrupt [IRQ 3]
IRQ 4 Selects the interrupt for a serial port A.
PS/2 Mouse Disabled
[Enabled]
Auto Detect If disabled, PS/2 mouse port will not
function.
USB Host Controller Disabled
[Enabled] If disabled, the USB ports do not
accept the USB device class 3 (HID:
Human Interface Device).
Legacy USB
Support Disabled
[Enabled] Selects whether the USB keyboard is
made available in OS which does not
support USB formally.
Parallel ATA Disabled
Channel 0
Channel 1
[Both] Selects parallel ATA is enabled or
disabled.
Serial ATA Disabled
[Enabled] Selects whether the serial ATA is
enabled or disabled.
[ ]: Factory-set
