9-52 Upgrading Your Server
10. Secure the backup device with the provided screws.
Tighten two screws on each side.
NOTES:
„ Be sure to use the screws provided with the backup device.
„ Position the backup device so that the device screw holes align with
the screw holes in the device carrier.
„ If you feel difficult to connect the cable of the long device such as
N8151-54F internal AIT, slide the device to the front and then
connect the cable.
11. Connect the power extension cable and interface cable to the device.
Screw hole not used
K410-130 (00)
SCSI Cable
Power Cable
(Attached)
IDE Cable
(Attached)
Power Cable
(Attached)
