Configuring Mesh Networking
9-19
1.
The Trion IT department verifies connectivity with both of the AP-5131s following the
instructions in
Testing Connectivity on page 3-13
2.
The Trion IT Department installs the AP1 on a wall with the antennas orienting outward into
the shipping and receiving yard. The team then installs the AP2 on a wall on the receiving
shack in the shipping yard.
The Trion IT department follows the instructions in
Wall Mounted Installations on page 2-13
to install AP1 and AP2.
AP1
AP2
