Monitoring Statistics
7-25
8.
Click the
Logout
button to securely exit the AP-5131 Symbol Access Point applet. A prompt
displays confirming the logout before the applet is closed.
7.5.1 Viewing MU Details
Use the
MU Details
screen to display throughput, signal strength and transmit error information for
a specific MU associated with the AP-5131.
The MU Details screen is separated into four fields; MU Properties, MU Traffic, MU Signal, and MU
Errors. The
MU Properties
field displays basic information such as hardware address, IP address,
and associated WLAN and AP. Reference the
MU Traffic
field for MU RF traffic and throughput data.
Use the
RF Status
field to reference information on RF signal averages from the target MU. The
Error
field displays RF traffic errors based on retries, dropped packets and undecryptable packets. The MU
Details screen is view-only with no user configurable data fields.
To view details specific to an individual MU:
1.
Select
Status and Statistics
->
MU Stats
from the AP-5131 menu tree.
2.
Highlight a specific MU.
3.
Select the
MU Details
button.
4.
Refer to the
MU Properties
field to view MU address information.
IP Address
Displays the IP address of the MU.
WLAN Association
Displays the name of the WLAN the MU is associated with. Use
this information to assess whether the MU is properly grouped
within that specific WLAN.
PSP State
Displays the current PSP state of the MU. The
PSP Mode
field has
two potential settings. PSP indicates the MU is operating in Power
Save Protocol mode. In PSP, the MU runs enough power to check
for beacons and is otherwise inactive. CAM indicates the MU is
continuously aware of all radio traffic. Symbol recommends CAM
for those MUs transmitting with the AP frequently and for periods
of time of two hours.
HW Address
Displays the Media Access Control (MAC) address for the MU.
Radio Association
Displays the name of the AP MU is currently associated with. If the
name of the
AP-5131
requires modification, see
.
