Symbol Technologies AP-5131 User Manual
Page 254
AP-5131 Access Point Product Reference Guide
6-68
2.
Refer to the
Proxy Configuration
field to define the proxy server’s retry count and timeout
values.
3.
Use the
Add
button to add a new proxy server. Define the following information for each
entry
:
Retry Count
Enter a value between 3 and 6 to indicate the number of times the
AP-5131 attempts to reach a proxy server before giving up.
Timeout
Enter a value between 5 and 10 to indicate the number of elapsed
seconds causing the AP-5131to time out on a request to a proxy
server.
Suffix
Enter the domain suffix (such as myisp.com or mycompany.com) of
the users sent to the specified proxy server.
RADIUS Server IP
Specify the IP address of the Radius server acting as a proxy server.
Port
Enter the TCP/IP port number for the Radius server acting as a proxy
server. The default port is 1812.
