Symbol Technologies AP-5131 - Manual (Page 204)

AP-5131 Access Point Product Reference Guide 6-18
Default (hexadecimal) keys for WEP 128 include:
6. Click the Apply button to save any changes made within the WEP 64 Setting or WEP 128
Setting field of the New Security Policy screen.
7. Click the Cancel button to undo any changes made within the WEP 64 Setting or WEP 128
Setting field and return to the WLAN screen. This reverts all settings to the last saved
configuration.
6.7 Configuring KeyGuard Encryption
KeyGuard is a proprietary encryption method developed by Symbol Technologies. KeyGuard is
Symbol's enhancement to WEP encryption, and was developed before the finalization of WPA-TKIP.
This encryption implementation is based on the IEEE Wireless Fidelity (Wi-Fi) standard, 802.11i.
WPA2-CCMP (not KeyGuard) offers the highest level of security among the encryption methods
available with the AP-5131.
1. Select Network Configuration -> Wireless -> Security from the AP-5131 menu tree.
If security policies supporting KeyGuard exist, they appear within the Security
Configuration screen. These existing policies can be used as is, or their properties edited
by clicking the Edit button. To configure a new security policy supporting KeyGuard,
continue to step 2.
2. Click the Create button to configure a new policy supporting KeyGuard.
The New Security Policy screen displays with no authentication or encryption options
selected.
Key 1 1011121314
Key 2 2021222324
Key 3 3031323334
Key 4 4041424344
Key 1 101112131415161718191A1B1C
Key 2 202122232425262728292A2B2C
Key 3 303132333435363738393A3B3C
Key 4 404142434445464748494A4B4C
