Monitoring Statistics 7-23
2. Click Apply to save any changes to the Radio Histogram screen. Navigating away from the
screen without clicking Apply results in changes to the screens being lost.
3. Click Undo Changes (if necessary) to undo any changes made to the screen. Undo Changes
reverts the settings to the last saved configuration.
4. Click Logout to securely exit the AP-5131 Symbol Access Point applet. A prompt displays
confirming the logout before the applet is closed.
7.5 Viewing MU Statistics Summary
Use the MU Stats Summary screen to display overview statistics for mobile units (MUs) associated
with the AP-5131. The MU List field displays basic information such as IP Address and total
throughput for each associated MU. The MU Stats screen is view-only with no user configurable data
fields. However, individual MUs can be selected from within the MU Stats Summary screen to either
ping to assess interoperability or display authentication statistics.
To view AP-5131 overview statistics for all of the MUs associated to the AP-5131:
1. Select Status and Statistics - > MU Stats from the AP-5131 menu tree.
