SMC Networks TigerSwitch 100 - Manual (Page 72)

C
ONFIGURING THE
S
WITCH
2-42
Command Usage
Entries specified via the Web interface are permanent. Entries specified via
the CLI can be made permanent or can be set to be deleted on reset.
Web – Click Address Table, Static Addresses. Specify the interface, the
MAC address and VLAN, then click “Add Static Address.”
CLI – This example adds an address to the static address table, but sets it
to be deleted when the switch is reset.
Displaying the Address Table
The Dynamic Address Table contains the MAC addresses learned by
monitoring the source address for traffic entering the switch. When the
destination address for inbound traffic is found in the database, the
packets intended for that address is forwarded directly to the associated
port. Otherwise, the traffic is flooded to all ports.
Console(config)#mac-address-table address 00-e0-29-94-34-de ethernet
1/1 vlan 1 delete-on-reset
3-100
Console(config)#
