C
ONFIGURING THE
S
WITCH
2-94
CLI – This example creates trunk 1 with ports 11 and 12. Just connect
these ports to two static trunk ports on another switch to form a trunk.
Configuring SNMP
The switch includes an onboard agent that continuously monitors the
status of its hardware, as well as the traffic passing through its ports, based
on the Simple Network Management Protocol (SNMP). A network
management station can access this information using management
software. Access rights to the onboard agent are controlled by community
strings. To communicate with the switch, the management station must
first submit a valid community string for authentication. The options for
configuring community strings and related trap functions are described in
the following sections.
Console(config)#interface port-channel 1 3-85
Console(config-if)#exit
Console(config)#interface ethernet 1/11
3-85
Console(config-if)#channel-group 1 3-167
Console(config-if)#exit
Console(config)#interface ethernet 1/12
Console(config-if)#channel-group 1
Console(config-if)#end
Console#show interfaces status port-channel 1
3-95
Information of Trunk 1
Basic information:
Port type: 1000t
Mac address: 22-22-22-22-22-2c
Configuration:
Name:
Port admin status: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full, 1000full,
Flow control status: Disabled
Port security: Disabled
Port security action: None
Current status:
Created by: User
Link status: Up
Port operation status: Up
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/11, Eth1/12,
Console#
