SMC Networks TigerSwitch 100 - Manual (Page 138)

C
ONFIGURING THE
S
WITCH
2-108
Web – Click IGMP, IGMP Member Port Table. Specify the interface
attached to a multicast service (via an IGMP-enabled switch or multicast
router), indicate the VLAN that will propagate the multicast service,
specify the multicast IP address, and then click Add. After you have
completed adding ports to the member list, click Apply.
CLI – This example assigns a multicast address to VLAN 1, and then
displays all the known multicast services supported on VLAN 1.
Showing Device Statistics
You can display standard statistics on network traffic from the Interfaces
Group and Ethernet-like MIBs, as well as a detailed breakdown of traffic
based on the RMOM MIB. Interfaces and Ethernet-like statistics display
errors on the traffic passing through each port. This information can be
used to identify potential problems with the switch (such as a faulty port or
Console(config)#ip igmp snooping vlan 1 static 224.0.0.12
ethernet 1/12
3-140
Console(config)#exit
Console#show mac-address-table multicast vlan 1
3-142
VLAN M'cast IP addr. Member ports Type
---- --------------- ------------ -------
1 224.0.0.12 Eth1/12 USER
1 224.1.2.3 Eth1/12 IGMP
Console#
