Weighted Round Robin (WRR). Up to eight separate traffic priorities are
defined in IEEE 802.1p. The default priority levels are assigned according
to recommendations in the IEEE 802.1p standard as shown in the
following table.
The priority levels recommended in the IEEE 802.1p standard for various
network applications are shown in the following table. However, you can
map the priority levels to the switch’s output queues in any way that
benefits application traffic for your own network.
• Priority – CoS value. (Range: 0 to 7, where 7 is the highest priority)
Queue
0 1 2 3
Pr
io
rit
y
0
1
2
3
4
5
6
7
Priority Level Traffic Type
1 Background
2 (Spare)
0 (default) Best Effort
3 Excellent Effort
4 Controlled Load
5 Video, less than 100 milliseconds latency and jitter
6 Voice, less than 10 milliseconds latency and jitter
7 Network Control
