SMC Networks TigerSwitch 100 - Manual (Page 127)

C
ONFIGURING
SNMP
2-97
Web – Click SNMP, SNMP Configuration. Fill in the Trap Manager IP
Address box and the Trap Manager Community String box, mark Enable
Authentication Traps if required, and then click Add.
CLI – This example adds a trap manager and enables authentication traps.
SNMP IP Filtering
The switch allows you to create a list of up to 16 IP addresses or IP
address groups that are allowed access to the switch via SNMP
management software.
IP addresses that are permitted SNMP access are specified by an IP
address together with a subnet mask that identifies the range of valid
addresses. For example:
IP address 192.168.1.1 and mask 255.255.255.0 — Specifies a valid IP
address group from 192.168.1.0 to 192.168.1.255.
Console(config)#snmp-server host 10.1.19.23 batman 3-61
Console(config)#snmp-server enable traps authentication 3-63
