C
LASS OF
S
ERVICE
C
ONFIGURATION
2-87
Command Attributes
• DSCP Priority Table – Shows the DSCP Priority to CoS map.
• Class of Service Value – Maps a CoS value to the selected DSCP
Priority value. Note that “0” represents low priority and “7” represent
high priority.
Web – Click Priority, IP DSCP Priority. Select a DSCP priority value from
the DSCP Priority Table by clicking on it with your cursor, enter a value in
the Class of Service Value field, and then click Apply. Be sure to also select
IP DSCP from the IP Precedence, DSCP Priority Status menu.
38, 40, 42 5
48 6
46, 56 7
IP DSCP Value CoS Value
