1.11

L

AYOUT

& I

NSTALLATION

1
2
3
4
5
6
7
8
9
10
11
12
13
14
A

L

A

Y

OUT

& I

NST

ALLA

TION

Plug in and power up

1

Plug the non-pronged end of the supplied AC power cord into the AC socket on the

machine and the pronged end into a properly grounded AC outlet.

IMPORTANT: Be sure not to turn the power on until after you unlocked the scanner unit locking

switch. (See page 1.7.)

2

Turn on the power switch. The markings are international standards:

I means on, O means off.

It will take a few seconds for the machine to warm up. The machine shows:

Warming up

Then the machine shows:
The following display doesn’t appear in F-300 model.

Mirror Locked

To use the machine, turn off the transport mode.

NOTE: While the power is on, the scanner lamp will always light, but this is not machine

failure, it is needed to prolong the life of your machine’s scanner lamp.

Turning off the transport mode

When the machine is in the transport mode, the machine shows:

Mirror Locked

To turn off the transport mode:

1

Press

MENU

, , 1, 4.

Mirror Locked :On

/

/Enter

2

Press or to select “Off” and press

ENTER

.

The scanner unit will move to home position and the machine is ready to use.

IMPORTANT: • The transport mode doesn’t appear in F-300 model.

• If you must reship the machine, turn this mode to on, then power off and lock the

scanner unit by sliding the lock switch.
