PAPER HANDLING
User's Manual 3-14
Unloading Continuous Forms
To unload continuous forms:
1. Make sure that the paper select lever is set to the rear position.
2. Press the LOAD button. The continuous forms paper is retracted to
the park position. If the paper cannot be retracted in one operation,
continue to press the LOAD button until the paper is parked.
NOTE
The printer can retract continuous forms paper a maximum of
55.8 cm (22 inches) per operation.
3. To remove the paper, raise the tractor paper holders and lift out the
paper.
Installing the Tractor Unit
Install the tractor unit by following the procedure below if it happens to be
disengaged from the studs.
1. Turn off the printer.
2. Remove the cut sheet stand and open the acoustic cover.
3. Hook the notch of the tractor unit against stud 1, and then rotate the
unit downward so as to set the other notch onto stud 2.
Stud 1
Stud 2
Stud 1
Stud 2
Acoustic cover
