PAPER HANDLING
User's Manual 3-2
OVERVIEW OF PAPER
OPERATIONS The following levers and buttons are used in paper handling:
• Paper select lever at the top left corner of the printer
• Paper thickness lever at the top right corner of the printer
• LF/FF, TEAR OFF, LOAD, and MENU buttons on the control panel
(A different function is enabled when each button is pressed in
conjunction with the ONLINE button.)
The following figure shows the location of each lever and button:
Printer levers and buttons
Table 3.1 summarizes the use of levers and buttons in paper handling. More
detailed information is provided later in this chapter.
NOTE
To load or feed paper, the printer must be:
• Online but not receiving or printing data
• Offline but not in setup mode
To micro-feed paper, which is done with the ONLINE button, the printer
must be:
• Offline but not in setup mode.
Paper
thickness
lever
Control panel
Paper select
lever
Menu indicators
Buttons
